SRV05-4 ESD Protection Array Diode – SOT-23 6L

24.00 (Incl. of GST 18%)
GST Credit of 3.66available.
Know More

In stock

  • Reverse Stand-Off Voltage: 5V(Max)
  • Reverse Breakdown Voltage: 6V
  • Clamping Voltage: 12.5V – 17V
  • Junction Capacitance: 3pF – 5pF
  • Peak Pulse Current: 12A
  • ESD Protection: IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact)
  • JEDEC SOT-23 6L package
SKU: KSTI0913 Category: Tags: , , , , , ,

Quantity based pricing table

MinMaxUnit Price
1924.00
101922.56
204921.60
509920.64
10019919.68
20029918.72
300And more.18.24

24.00 (Incl. of GST 18%)
GST Credit of 3.66available.
Know More

Our office will remain closed on 24th and 25th Mar, 2024 on account of Holi. All orders placed after 04:30PM on 23rd Mar, 2024 will be dispatched starting from 26th Mar, 2024.
For B2B orders, contact us on sales@ktron.in

Description

The unique design of the SRV05-4 devices incorporates eight surge rated, low capacitance steering diodes and a TVS diode in a single package. During transient conditions, the steering diodes direct the transient to either the positive side of the power supply line or to ground. The internal TVS diode prevents over-voltage on the power line, protecting any down-stream components.

The SRV05-4 has a low typical capacitance of 3pF and operates with virtually no insertion loss to 1GHz. This makes the device ideal for protection of high-speed data lines such as USB 2.0, Firewire, DVI, and gigabit Ethernet interfaces. The low capacitance array configuration allows the user to protect four high-speed data or transmission lines. The low inductance construction minimizes voltage overshoot during high current surges. They may be used to meet the ESD immunity requirements of IEC61000-4-2, Level 4 (±15kV air, ±8kV contact discharge).

Features

  • ESD protection for high-speed data lines to

        IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact)

        IEC 61000-4-4 (EFT) 40A (5/50ns)

        IEC 61000-4-5 (Lightning) 12A (8/20μs)
  • Array of surge rated diodes with internal TVS Diode
  • Small package saves board space
  • Protects four I/O lines
  • Low capacitance: 3pF typical
  • Low clamping voltage
  • Low operating voltage: 5.0V
  • Solid-state silicon-avalanche technology

Specification

Additional information

Weight0.05 g
