Rocker Switch DPDT – 6A
GST Credit of ₹3.24available.
- Dual Pole Dual Throw Rocker Switch
- Current Capacity: 6 A @ 250V AC/DC
- High Quality, Reliable
- Easy to mount, using flash mount points
The switch is a Dual Pole Dual Throw – DPDT Rocker Switch. The switch has current rating of 6A @ 250V AC/DC. Also it is a 2 way switch, and not a conventional 3 way DPDT Switch. Both common pins are connected to one side of the their respective pins, and on toggling the switch, the common pins are connected to pins on the other side.
- 2 position DPDT Switch
- 6A Current Rating @ 250V AC/DC
- Flash mounting points
The internal working diagram of the switch:
As visible in the diagram, the outputs of the DPDT Rocker switch can be taken from pins 3 and 4, whereas pins 1,2 are for different inputs, and same way, pins 5,6 are for different inputs. At a time, pins 3,4 are short to pins 1,2 or pins 5,6 respectively.
